Grove Published 3-22-2021, Control # 702-02 4-79
GRT8120 OPERATOR MANUAL OPERATING PROCEDURES
7 Speedometer
Shows the cranes
travel speed in the selected unit of measure (km/h
- mph).
8
Battery/Charging
Voltage Indicator
Shows the battery voltage when the engine is off and the charging
voltage when the engine is running.
Red Indicator - Indicates the battery voltage is less than 20V or
greater than 30V.
9
Hydraulic Oil
Temperature indicator
Shows the hydraulic oil temperature in the selected unit of measure
(°C / °F).
If indicator is yellow or red, safely stop crane operation and let
hydraulic oil cool by running engine at idle with no functions
actuated.
Item Name Symbol Description
