10 Calibration
SERVO VALVE
Unit [n] > Calibration > Servo Valve
Use to calibrate the servo valve to the sample transducer. The servo valve should always be
recalibrated after a pressure calibration has been performed. The pressure transducer should be
calibrated before starting this calibration procedure.
Ensure the pressure transducer has been calibrated before performing this pro-
cedure. Go to Unit [n] > Unit Configuration and view the calibration information.
Contact your Micromeritics Service Representative if calibration dates are not listed.
Click Start. The window closes when the calibration is complete.
Click Cancel to stop the calibration process.
SAVE CALIBRATION TO FILE
Unit [n] > Calibration > Save to File
Use to save the current calibration settings to a backup file which can later be reloaded using the
Unit [n] > Calibration > Load from File menu option.
The default file naming convention for calibration files can be used or the file name can be
changed. The default file name of 0217-2013-04-25.CAL is interpreted as:
0217 Analyzer serial number
2013-04-25 Date the calibration file was saved
.CAL File name extension
10 - 4
TriStar II Plus Operator Manual
303-42800-01 (Rev M ) — Sep 2023
