Milnor MilTouch - Data Transfer with the Miltouch PC Programmer Application

Pellerin Milnor Corporation 101
10. If you imported files from a USB flash drive, touch
to unmount the flash drive. The
available media indicator in the bottom right of the Data Transfer display changes from
green to red
, which indicates the controller no longer recognizes a connected USB
device.
11. Remove the USB flash drive.
BNCLJP06 / 2020512
BNCLJP06 0000200060 F.2 12/14/20 1:58 PM Released
5.3 Data Transfer with the MilTouch™ PC Programmer
Application
BNCLJO06.C11 0000187099 E.2 F.2 F.9 11/6/20 2:13 PM Released
NOTE: If you are not using the MilTouch™ PC programmer application, see Section
5.2 : Data Transfer with the MilTouch™ Controller, page 96.
From the Data Transfer display, you can export wash formulas prepared with the MilTouch™
PC programmer application to a USB flash drive for sharing. You can also export wash formula
sets and configuration files to a USB device or the hard drive of the computer running the pro-
grammer application to keep as backup data.
To begin data transfer:
1. Touch
on the Home display on the MilTouch™ PC programmer application to show the
Data Transfer display on the programmer application.
2. A dialog box (not shown) appears, which reminds you that only files saved in the root of the
USB flash drive are available for import. In the dialog box, touch
to dismiss it.
The following figure shows how the Data Transfer display appears on the MilTouch™ pro-
grammer application.
In the following figure, these definitions apply:
internal pertains to a data storage location that only the programmer application can use.
Changes you make to configuration and wash formula decisions with the programmer appli-
cation apply to the data at this location.
external pertains to the root of the computer’s hard drive or the root of the USB flash drive.
export copy data from the internal to an external data storage location.
import copy data from an external to the internal data storage location.
Data Transfer
