Milnor MilTouch - Table 10 Outputs on 8-Output 16-Input Boards #3 and #4 (for WTB+ Only)

84
Pellerin Milnor Corporation
Table 9 Outputs on 24-Output Board #2 (cont'd.)
Output #
(Board)
Output #
(Display)
Connections on
Board
Function
Description
22 62 2MTA14-10 & 14-9
Alt. Decel
Safety
Actuate to send a signal to the
inverter that indicates it is safe
to decelerate the motor. This
output is actuated whenever the
machine is fully powered on.
23 63 2MTA14-10 & 14-19
Move to Wash
Posi.
On hydraulic tilting machines,
actuate to bring the machine to
the wash position.
Table 10. Outputs on 8-output 16-input Boards #3 and #4 (for WTB+ only)
Output #
(Board)
Output #
(Display)
Connections on
Board
Function
Description
8/16 Board 3
0 64 3MTA5-10 & 5-19
Dryell Blow
This output is used to dry the
chute after a “Dryell Flush” on
older machines with a separate
chute and door.
1 65 3MTA5-9 & 5-18
Brake Safety
The controller automatically
actuates this output on boot up
to protect the inverter from
power failure.
2 66 3MTA5-8 & 5-17 not used
—
3 67 3MTA5-7 & 5-16 Load Desired
This output signals an allied
(non-Miltrac™) loading device
that the washer is ready to ac-
cept a load.
4 68 3MTA5-4 & 5-14
Dryell Flush
Flush the Integrated Door
Chute with water. This output
is automatically actuated dur-
ing the loading process to help
goods slide down the chute.
5 69 3MTA5-3 & 5-13
Discharge
Terminated
This output signals an allied
(non-Miltrac™) discharge de-
vice that the washer has fin-
ished discharging its goods.
6 70 3MTA5-2 & 5-12
Open Bifold
Door
Opens the bifold door if all
safety conditions are met.
7 71 3MTA5-1 & 5-11
Close Bifold
Door
Closes the bifold door if all
safety conditions are met.
8/16 Board 4
0 96 4MTA5-10 & 5-19
Dry Code Bit
0
Dry codes passed to an adja-
cent allied (non-Miltrac™)
Troubleshooting
