56
Pellerin Milnor Corporation
If your machine encountered an error while it was receiving or discharging a load:
1. Activate manual mode.
2. Use the functions on the Manual Override display to reposition the machine, if necessary.
3. On the Manual Override display, use the Load or Discharge function (the fault recovery se-
quences) to return the machine to automatic operation.
BNCLDO03 / 2020465
BNCLDO03 0000247025 B.3 11/12/20 1:38 PM Released
4.4 Manual Mode
BNCLDO01.C05 0000188683 E.2 B.3 C.6 8/21/20 2:07 PM Released
In manual mode, the operator controls the washer-extractor with the outputs on the Manual
Override display. Manual mode can be used to re-position the machine after a fault occurs, trou-
bleshoot error conditions, or perform maintenance tasks according to the service and maintenance
manual.
The Manual Override display, shown in the following figure, appears when you activate manual
mode. The Manual Override display also appears when an error occurs during automatic
operation.
To activate manual mode:
• From the Home display, touch
, or touch Manual Mode from the selection list shown in
Figure 1: The Home Display, page 8 .
• From the Automatic Loading/Discharging State windows (see Figure 2: Example Loading
State, page 9 ), touch
.
• From the error code dialog box (if your machine has encountered an error), touch
.
Troubleshooting
