12
Pellerin Milnor Corporation
2 Configuration
BNCLDP01 / 2021463
BNCLDP01 0000241719 C.2 11/10/21 9:58 AM Released
2.1 Machine Configuration
BNCLJP03.C03 0000209629 E.2 C.2 E.3 1/2/20 1:22 PM Released
Your machine was configured at the factory and the configuration values were recorded on the
MilTouch™ Configuration form included with your machine. You will find a copy of this com-
pleted form in the packet of documentation shipped in the machine cylinder. The values set at the
factory and recorded on the MilTouch™ Configuration form are the optimum or required settings
for your machine.
Most configuration decisions are hardware-dependent. The only reason to modify hardware-de-
pendent settings is to accommodate modifications to your machine’s hardware.
CAUTION: Careless modification of hardware-dependent settings — Is likely to
degrade machine performance and may cause damage or malfunction.
� Do not make unauthorized changes to hardware-dependent configura-
tion settings.
� Consult Milnor
®
Technical Support before you change hardware-de-
pendent settings.
2.1.1 The Main Configuration Display
BNCLDP01.C01 0000242100 E.2 C.2 A.9 1/2/20 1:22 PM Released
From the Configuration display, you can configure the MilTouch™ controller based on your ma-
chine’s model, features, and capabilities.
Touch
on the Home display. A selection list with three options appears:
• Touch Configuration to access the (main) machine configuration decisions. The Main Con-
figuration display is shown in Figure 4, page 13.
• Touch Configure WTB to configure the automated chute (see Section 2.1.4 : WTB (Auto-
mated Chute) Configuration, page 19).
• Touch Program Post Dry to create and edit post-wash codes (see Section 3.2 : Post-wash Co-
des, page 37).
