Milnor MilTouch - Table 11 Outputs on 24-Output Board #4 (WTB+ Only); Table

Pellerin Milnor Corporation 85
Table 10 Outputs on 8-output 16-input Boards #3 and #4 (for WTB+ only) (cont'd.)
Output #
(Board)
Output #
(Display)
Connections on
Board
Function
Description
machine for the load exiting
the washer-extractor.
1 97 4MTA5-9 & 5-18
Dry Code Bit
1
2 98 4MTA5-8 & 5-17
Dry Code Bit
2
3 99 4MTA5-7 & 5-16
Dry Code Bit
3
4 100 4MTA5-4 & 5-14
Destination
Code Bit 0
Destination codes passed to an
adjacent allied (non-Miltrac™)
machine for the load exiting
the washer-extractor.
5 101 4MTA5-3 & 5-13
Destination
Code Bit 1
6 102 4MTA5-2 & 5-12
Destination
Code Bit
2
7 103 4MTA5-1 & 5-11
Destination
Code Bit 3
Table 11. Outputs on 24-Output Board #4 (WTB+ only)
Output #
(Board)
Output #
(Display)
Connections on
Board
Function
Description
0 104 4MTA13-
1 & 2MTA13-11
Hydraulic
Pump
Activates the hydraulic pump
used to tilt the machine and
move the chute.
1 105 4MTA13-2 & 13-12
Chute Up Raises the load chute if all
safety conditions are met.
2 106 4MTA13-3 & 13-13
Chute
Down
Lowers the load chute if all
safety conditions are met.
3 107 4MTA13-4 & 13-14
Discharge
Desired
This output signals an allied
(non-Miltrac™) discharge de-
vice that the washer is ready to
discharge.
4 108 4MTA13-5 & 13-15
Load Unload
Terminate
This output signals an allied
(non-Miltrac™) loading device
that the washer has received
the goods and returned to the
wash position.
5
109 4MTA13-6 & 13-16
Tilt Up Raises the machine rear if all
safety conditions are met.
6 110 4MTA13-7 & 13-17
Tilt
Down
Lowers the machine rear if all
safety conditions are met.
7
111 4MTA13-8 & 13-18
Speed Limited;
Balance
On 72046M5K models, this
output enables the balancing
system. On non-72046M5K
