Table 11 Outputs on 24-Output Board #4 (WTB+ only) (cont'd.)
Output #
(Board)
Output #
(Display)
Connections on
Board
Function
Description
18 122 4MTA14-10 & 14-7
Flag Down This output is used to align
loading and discharge devices
(usually devices that do not tra-
verse on a rail) with the
machine.
19 123 4MTA14-10 & 14-17 Sequencer
Load Unload
Term
These outputs determine the se-
quence in which groups of ma-
chines will load and discharge
in multi-machine laundries.
20 124 4MTA14-10 & 14-8
Sequencer Dis-
charge Desired
21 125 4MTA14-10 & 14-18
Sequencer Dis-
charge
Allowed
22 126 4MTA14-10 & 14-9 Sequencer
Flag Down
Discharge
23 127 4MTA14-10 & 14-19
not used
—
4.9.3 External Use Input and Output Specifications
BNCLJT01.C04 0000204750 E.2 A.3 C.3 1/2/20 1:22 PM Released
Two inputs are available for the customer’s use. These are:
• Timer Stop (timer halt), which suspends the formula timer when the input is actuated.
• External Fault, which causes the controller to issue the External fault error when the input is
actuated.
