• If your machine is equipped with, and configured for, an optional reuse tank, the
icon illuminates in the Machine Status area.
5. The water level falls.
6. When the water level falls below high level, the drain closes.
• If the drain valve to the sewer closes, the
icon extinguishes in the Machine Status
area.
• If the drain valve to the reuse tank closes, the
icon extinguishes in the Machine Sta-
tus area.
7. The cooldown valve re-opens. The
icon illuminates in the Machine Status area.
8. The drain and cooldown valves continue to open and close as needed to reach the desired
water level and temperature.
9. The step timer starts 15 seconds after the desired cooldown temperature is achieved. The tim-
er runs for one minute.
10. When the step time expires, the cooldown valve closes and the drain opens. The drain re-
mains closed only if the machine was programmed to not drain, as to prolong the cooldown
or allow the injection of chemicals into the cooler bath.
BNCLJP08 / 2019442
BNCLJP08 0000216461 C.3 10/28/19 2:42 PM Released
3.4 How to Modulate Water Valves to Regulate Incom-
ing Water Temperature
BNCLJP04.C01 0000206352 E.2 C.3 D.3 1/2/20 1:22 PM Released
When using both hot and cold water valves to achieve a programmed temperature, you can
achieve a more constant and accurate fill temperature more quickly if you understand the relation-
ship between the desired temperature and the temperature of a split fill (hot and cold valves open
simultaneously).
• If the desired temperature is hotter than the normal split temperature, program the hot water
valve open (HOT Water =
ON) and the cold water valve to open only to lower the fill
temperature (COLD Water =
Lower Fill Temp).
• If the desired temperature is colder than the normal split temperature, program the hot water
valve to open only to raise the fill temperature (HOT Water =
Raise Fill Temp) and the
cold water valve to remain open constantly (COLD Water =
ON).
