Milnor MilTouch - Table 7 Outputs on 8-Output 16-Input Boards #1 and #2; Table 8 Outputs on 24-Output Board #1

80
Pellerin Milnor Corporation
Table 7 Outputs on 8-output 16-input Boards #1 and #2 (cont'd.)
Output #
(Board)
Output #
(Display)
Connections on
Board
Function
Description
6 6 1MTA5-2 & 5-12 Chemical 2
Actuate to inject chemical 2,
usually detergent or bleach
7 7 1MTA5-1 & 5-11 Chemical 5
Actuate to inject chemical 5,
usually starch; also used to sig-
nal that a chemical delivery
system desires to inject
chemical.
8/16 Board 2
0 32 2MTA5-10 & 5-19
Fresh to
Machine
Actuate to fill the machine from
the fresh water inlets.
1 33 2MTA5-9 & 5-18 Tank to Sewer
Actuate to drain bath water
from the overhead tank to the
sewer.
2 34 2MTA5-8 & 5-17 Fresh to Tank
Actuate to fill the overhead
tank from the fresh water inlets.
3 35 2MTA5-7 & 5-16
Brake Safety
The controller automatically ac-
tuates this output on boot up to
protect the inverter from power
failure.
4 36 2MTA5-4 & 5-14 Door Lock Actuate to lock the door.
5 37 2MTA5-3 & 5-13 Steam in Tank
On machines with the overhead
tank option and tank-steam, ac-
tuate to heat the tank water.
6 38 2MTA5-2 & 5-12
Speed Limited;
Balance
On 72046M5K models, this
output enables the balancing
system. On non-72046M5K
MilTouch-EX™ models with
OoB detection, this output lim-
its the extract speed based on
the amount of imbalance.
7 39 2MTA5-1 & 5-11 3-wire Pulse
Simulates a start button to en-
gage 3-wire ciruit.
Table 8. Outputs on 24-Output Board #1
Output #
(Board)
Output #
(Display)
Connections on
Board
Function
Description
0 8 1MTA13-1 & 13-11 Tank to Machine
Actuate to fill the ma-
chine from the overhead
tank.
1 9 1MTA13-2 & 13-12 Alt. Accel/Decel
Used to change the accel/
decal rate of the cylinder
motor during extract and
coast down.
Troubleshooting
