Pellerin Milnor Corporation 69
4.7.1.3 Digital Outputs— Machine Idle
BNCLUT02.C13 0000208717 E.2 B.3 D.3 1/2/20 1:22 PM Released
When the machine is idle, you can actuate outputs to verify that the machine responds correctly.
Touch an output button to actuate the output. The actuated output displays
. Touch the button
again to turn the output OFF. All outputs turn OFF when you exit the Diagnostics display with
and return to the Home display.
4.7.1.4 Digital Outputs— Formula in Progress
BNCLUT02.C12 0000208718 E.2 B.3 D.3 1/2/20 1:22 PM Released
Diagnostic control of outputs is disabled while the machine runs a formula. However, when a for-
mula is in progress, you can monitor the outputs to observe certain events as they occur in a wash
formula cycle. For example, you can monitor when the water valves open and close.
4.7.1.5 Analog Channels (A/D inputs and D/A outputs)
BNCLDT01.C05 0000249607 E.2 B.3 A.3 1/2/20 1:22 PM Released
Touch to view analog inputs and outputs (shown in the following figure) to monitor the bath
temperature and level, the board voltage, and other conditions.
