6.1.1.1.2 If the Extract Step is a Final Extract
BNCLUF01.C05 0000185935 E.2 G.5 G.14 4/15/21 12:03 PM Released
1. The machine performs a preemptive recycle in drain speed.
2. After the recycle, the OoB detection system evaluates whether the amount of imbalance is
within the allowed threshold for the machine.
• If the imbalance is within the allowed threshold, the machine completes the extract step at
the programmed speed.
• If the imbalance exceeds the maximum allowed threshold value, the machine recycles the
extract sequence up to three times.
– If the imbalance falls within the allowed threshold before or by the third recycle at-
tempt, the machine completes the extract step at the programmed speed.
– If the imbalance remains above the maximum allowed threshold value after the third
recycle attempt, the machine completes the extract step at a reduced speed that is pro-
portional to the amount of imbalance.
3. The OoB detection system continues to monitor the imbalance until the end of the step.
6.1.1.1.3 If the Excursion Switch Trips
BNCLUF01.C06 0000185934 E.2 G.5 G.6 4/15/21 9:38 AM Released
If the excursion switch trips while the cylinder accelerates to the programmed extract speed, the
following events occur:
1. The machine performs a recycle.
2. After the recycle, the OoB detection system recalculates the amount of imbalance.
• If the new imbalance is less than the lowest threshold value, the machine completes the
extract step at the programmed speed.
• If the new imbalance is more than the maximum allowed threshold value, the machine
performs up to three recycles. If the imbalance remains above the maximum allowed
threshold value after the third recycle:
– During an intermediate extract, the controller cancels the step, displays the error “Too
Many Recycles,” and proceeds to the next bath step (non-extract step).
– During a final extract, the controller cancels the formula and displays the error “Too
Many Recycles.”
NOTE: If the controller cancels a formula because of an imbalance error, the goods will
require more dryer time.
6.1.1.1.4 If the Excursion Switch Does not Trip
BNCLUF01.C07 0000185933 E.2 G.5 F.3 4/14/21 4:17 PM Released
If the excursion switch does not trip while the cylinder accelerates to the programmed speed, the
machine completes the extract step at the programmed speed.
6.1.1.2 MilTouch-EX™ and MilTouch-EX™ WTB Models with Balancing
BNCLUF01.C08 0000185932 E.2 G.5 4/14/21 4:06 PM Released
Applicable Models 72046M5K, 72046M5K WTB
