Milnor MilTouch - Outputs; Table 6 Inputs on 8-Output 16-Input Board #4 (WTB+ Only)

Pellerin Milnor Corporation 79
Table 6. Inputs on 8-output 16-input Board #4 (WTB+ only)
Input #
(Board)
Input #
(Display)
Connection
on Board
Function
Description
0 48 4MTA4-1
Formula Bit 0 Formula bits received from an adja-
cent allied (non-Miltrac™) ma-
chine for the load entering the
washer.
1 49 4MTA4-2
Formula Bit 1
2 50 4MTA4-3
Formula Bit 2
3 51 4MTA4-4
Formula Bit 3
4 52 4MTA4-5
Formula Bit 4
5
53 4MTA4-6
Formula Bit 5
6 54 4MTA4-7
Allied Weight Bit 0
Allied weight bits received from an
adjacent allied (non-Miltrac™) ma-
chine for the load entering the
washer.
7 55
4MTA4-8
Allied Weight Bit 1
8 56 4MTA4-11
Allied Weight Bit 2
9
57
4MTA4-12
Allied Weight Bit 3
10 58 4MTA4-13
Allied Weight Bit 4
11 59 4MTA4-14
Allied Weight Bit 5
12 60 4MTA4-15
Allied Weight Bit 6
13 61 4MTA4-16
Allied Weight Bit 7
14 62 4MTA4-17
not used
—
15 63 4MTA4-18
not used
—
4.9.2 Outputs
BNCLDT01.C02 0000242899 E.2 A.3 B.3 6/4/20 11:01 AM Released
Table 7. Outputs on 8-output 16-input Boards #1 and #2
Output #
(Board)
Output #
(Display)
Connections on
Board
Function
Description
8/16 Board 1
0 0 1MTA5-10 & 5-19
Recirculation
Pump
On machines with the optional
recirculation feature, actuate to
flow bath water through the
door.
1 1 1MTA5-9 & 5-18 Cooldown
Actuate to open the optional
cooldown valve.
2 2 1MTA5-8 & 5-17 Flush
Actuate to open the flush valve
for chemicals.
3 3 1MTA5-7 & 5-16 Chemical 4
Actuate to inject chemical 4,
usually softener.
4 4 1MTA5-4 & 5-14 Chemical 1
Actuate to inject chemical 1,
usually alkali or detergent
5 5 1MTA5-3 & 5-13 Chemical 3
Actuate to inject chemical 3,
usually bleach for 36-inch or
larger models; sour for other
models.
