78
Pellerin Milnor Corporation
Table 5 Inputs on 8-output 16-input Board #3 (WTB+ only) (cont'd.)
Input #
(Board)
Input #
(Display)
Connection
on Board
Function
Description
9 41 3MTA4-12
Bifold Door Full Open This circuit closes when the bi-
fold door is open to receive a
load.
10 42 3MTA4-13
Allied Start Loading The allied (non-Miltrac™) load-
ing device sends this signal to
the machine to initialize the
loading sequence. Also known
as “Start Receiving.”
11 43 3MTA4-14
Rear Full Up This circuit closes when the ma-
chine is in the discharge (rear
fully-raised) position.
12 44 3MTA4-15
Allied Discharge
Terminate
This circuit closes when the ma-
chine finishes discharging its
load, and the allied (non-Mil-
trac™) discharge device signals
to the machine that it has suc-
cessfully received the load.
13 45 3MTA4-16
Allied Load Terminate This circuit closes when the ma-
chine finishes receiving a load,
and the allied (non-Miltrac™)
loading device signals to the ma-
chine that it has successfully
transferred its load.
14 46 3MTA4-17
Allied Start Discharge This circuit closes when the ma-
chine is ready to discharge its
load, and the allied (non-Mil-
trac™) discharge device signals
to the machine that it can re-
ceive the load.
15 47 3MTA4-18
Hydraulic Enable This circuit closes when you
press the Hydraulic Pump En-
abled button on the control pan-
el (see Figure 26: Manual
Override Display, page 57 ),
which allows the operator to
perform manual functions.
Troubleshooting
