Pellerin Milnor Corporation 83
Table 9 Outputs on 24-Output Board #2 (cont'd.)
Output #
(Board)
Output #
(Display)
Connections on
Board
Function
Description
7 47 2MTA13-8 & 13-18
Door Unlock
Pulse; Alt De-
cel Safety
On 72046M5K models, this
output is used for alt. decel
safety. On non-72046M5K
MilTouch-EX™ models with a
pulsing door interlock, this out-
put unlocks the door.
8 48 2MTA13-9 & 13-19 Chemical 10
Actuate to inject chemical 10.
9 49 2MTA13-10 & 14-1
Door Lock
Pulse
Actuate to lock the door.
10 50 2MTA14-11 & 14-2 Chemical 6
Actuate to inject chemical 6.
11 51 2MTA14-12 & 14-3 Chemical 7
Actuate to inject chemical 7.
12 52 2MTA14-4 & 14-13 Chemical 8
Actuate to inject chemical 8.
13 53 2MTA14-4 & 14-14 Chemical 12
Actuate to inject chemical 12.
14 54 2MTA14-10 & 14-5
Auto
Recirculation
On machines with auto recircu-
lation, the controller automati-
cally actuates this output when
the desired water level is
satisfied.
15 55 2MTA14-10 & 14-15 Drain Motor
Actuate to run Drain motor on
multi-motor machines.
16 56 2MTA14-10 & 14-6
Low Extract
Speed
Actuate to run Low Extract
motor on multi-motor
machines.
17 57 2MTA14-10 & 14-16
High Extract
Speed
Actuated to run High Extract
motor on multi-motor
machines.
18 58 2MTA14-10 & 14-7 MilTrench
Prevents multiple machines
from draining at the same time
when doing so would overflow
the trench.
19 59 2MTA14-10 & 14-17
Move to Load
Posi.
On hydraulic tilting machines,
actuate to bring the machine to
the load position.
20 60 2MTA14-10 & 14-8
AmpSaver
No longer supported. Prevents
multiple machines from ex-
tracting at the same time if
doing so would overload the
circuit.
21 61 2MTA14-10 & 14-18
Move to Wash
or Load
On hydraulic tilting machines,
actuate this output to enable
the tilting circuit.
Troubleshooting
