58
Pellerin Milnor Corporation
Bifold Door (F1) — This function opens or closes the bifold door. The chute must be down.
Hold the Hydraulic Pump Enabled button to operate the door.
Opens the bifold door. The door is fully open when the “Bifold Door Full Open” input
is actuated.
Closes the bifold door. The door is fully closed when the “Bifold Door Closed” input is
actuated.
Tilt (F2) — This function tilts the rear up or down. Hold the Hydraulic Pump Enabled button
to tilt the machine.
Raises the machine rear. The “Rear Full Up” input actuates when the rear is fully raised
(when the machine is in the discharge position).
Lowers the machine rear. The “Load Position” input actuates when the rear is fully
down (when the machine is in the load position).
Chute (F3) — This function moves the loading chute up or down. The bifold door must be
closed. Hold the Hydraulic Pump Enabled button to move the chute.
Raises the load chute. The “Chute Up Left Lock” and “Chute Up Right Lock” inputs
actuate when the chute is fully raised and locked into the up position.
Lowers the load chute. The “Chute Down Left Lock” and “Chute Down Right Lock”
inputs actuate when the chute is fully lowered and locked into the down position.
Load (F4) — This function allows the machine to recover from faults that occur during loading.
The machine must be in the load position: rear down, bifold door open, and chute down. Push the
Hydraulic Pump Enabled button to start/stop the sequence.
Starts the loading recovery sequence, described in Section 4.5.1 : The Loading Recov-
ery Sequence, page 59.
Stops the loading recovery sequence.
Discharge (F5) — This function allows the machine to recover from faults that occur during
discharge. The machine must be in the discharge position: rear up, bifold door closed, chute up
and locked. Push the Hydraulic Pump Enabled button to start/stop the sequence.
Starts the discharging recovery sequence, described in Section 4.5.2 : The Discharging
Recovery Sequence, page 60.
Stops the discharging recovery sequence.
