Convenient use
5
6
Setting media compensation
Correct the feeding rate of media after the type of media is replaced or the temperature of Heater is changed.
If the correction value is not appropriate, stripes may appear on the print, thus resulting in a poor print.
Setting media compensation
Print the compensation pattern then correct the feeding rate of media.
1
Set a media.( P.2-6)
2
Press the key in the local mode.
3
Press the key.
4
Select the type (1-4) by pressing the keys.
• When any heater temperature is changed, first make sure that the [ CONSTANT ] lamps light and the
preset temperatures have been reached, and then start correction.
• On completion of [MEDIA COMP.] during use of a roll media, the media returns to the printing origin.
Then the roll media in the rear of this machine will slacken.
Before printing, take up the slack in the roll media by hand; a loose roll media can result in an inferior
image quality.
• When printing is to be performed while using the take-up device, set the media first and then perform
[MEDIA COMP.].
• Print two bands as the compensation pattern.
• Adjust so that an even color density is obtained around the boundary between the two bands.
Second band
First band
Media advance direction
