MINICAM PROTEUS - CPL150 S Connections and Descriptions

A Heavy duty rear connector
B Multi-frequency sonde
C Lowering handle
D Manual height adjusters
E Manual elevator
F Connection point for the auxiliary module
G Connector for the camera
H Quick release mechanism
J Crawler wheel
K Pressurisation Point
CPL150S Connections and Descriptions
A
G
H
H
H
F
D
E
A
B
J
J
J
C
K
