Testing the system
Test the system before use to make sure the system performs correctly.
CAUTION!
Risk of serious injuries by falling crawler!
During the testing of the system make sure that the crawler
is not positioned too close to the open manhole! When test-
ing the driving functions the crawler may fall into the man-
hole. Any person in the manhole may suer serious injuries.
CAUTION!
Risk of disorientation and temporary blindness!
The illumination on the PROTEUS
™
inspection system use
high power LED lighting with narrow angle secondary optics.
During the testing and use of the system never look
directly at the camera or auxiliary module illumination.
When checking the illumination use a low power setting and
view from an angle greater than 50° from the centre of the
module.
Check the following system functions:
1 Control function of the crawler using the left joystick:
i Drive forwards and backwards.
ii Steer left and right.
2 Control function of the camera using the right joystick
(If Pan and Rotate camera head):
i Rotation left and right.
ii Pan up and down.
3 Lighting control of camera head and auxiliary module
(if tted):
i Turn the light intensity up and down.
4 Check function of the rear view camera and rear lights (if
auxiliary module is tted):
i Press the Backeye button.
Camera view will change to rear view.
ii Turn the light intensity up and down.
iii Press the Backeye button again. Camera view will
revert to forward view.
42
Version LMinicam Proteus
