Version L Minicam Proteus
Inclination Logging on the CCU
(If logging inclination using a PC application, please see the instruction
manual for that application.)
Setting up the Crawler
Setting the Inclination Polarity
Some Proteus crawlers produce an inclination signal which works up-
side-down (‘reversed’). For these crawlers you can tell the CCU to swap
the signal around.
• When you lift the front of the crawler, the inclination values
shown on the CCU screen should show POSITIVE values.
• When you lift the rear of the crawler, the inclination values
shown on the CCU screen should show NEGATIVE values.
If you nd that this is not true for your crawler, you may need to change
the “Inclination Polarity”.
• To change the Inclination Polarity, press for Setup.
• Then select the menu item Survey / Inclination.
• Then the menu item Inclination Polarity.
• From there you can select Standard or Reversed, then press .
Inclination Zero Calibration
The inclination sensor on some Proteus crawlers should be ‘calibrated’,
Minicam recommends that this is done before every inclination survey.
