MINICAM PROTEUS - Power on Sequence; Power off Sequence

Power ON sequence
1 With the system power OFF, connect all system components: Cable
reel, crawler, camera
2 Press ON/OFF button to power the control unit ON.
3 Read and acknowledge the on-screen prompt.
4 Press the ALL STOP button.
5 If the control unit detects a crawler connected, the system will fully
power up. The red light next to the ALL STOP button will turn o.
Video will be displayed and crawler/camera status information will be
displayed on the right hand side of the screen.
NOTE!
If the control unit does not detect a crawler connected, the
system will not fully power up. The control unit will sound an
audible beep several times and the red light next to the ALL
STOP button will be illuminated. If this should happen, rst
check all connections on the system are made correctly. If
the problem persists then contact the Minicam Service
Centre or Accredited Minicam Partner in your country.
NOTE!
Details of the nearest Minicam Service Centre and Accredited
Minicam Partners world-wide are made available on the
website www.minicam.co.uk
Power OFF sequence
1 Press the ALL STOP button. The red light next to this button will
illuminate.
2 Press the ON/OFF button and press OK to conrm.
3 The control unit will now power down.
4 The system can now be disconnected.
NOTE!
Always t the protective caps when the crawler, camera or
auxiliary module is not in use to protect from ingress of dirt
and moisture.
47
Version L Minicam Proteus
