A Coiled Link cable (shown) or Extension Reel Cable (not shown) plugs
directly into the CCU.
B Interchangeable camera head (CAM025 shown).
The interchangeable camera head allows the operator to use the
CAM026 pan
and rotate camera instead of the supplied CAM025
self-levelling axial camera. This provides
great exibility to meet
demanding inspection requirements.
NOTE!
The CCU can power the compatible coiler without the use of
External Charger PSP24 or Proteus Battery Pack BPP24 .
Connections and Descriptions
B
A
127
Version L Minicam Proteus
