MINICAM PROTEUS - CCU Overview

4
13
5
9 10
11
2
1
3
12
7
8
6
1 Daylight viewable screen 1024 x 768
pixels
2 Left joystick for crawler control
3 Right joystick for camera control
4 Speaker
5 ON/OFF button
6 ALL STOP button
7 Crawler function keys
8 Survey Function keys
9 Media function keys
10 Camera function keys
11 Snapshot key
12 Recording and playback
keys
13 Keyboard
CCU Overview
45
Version L Minicam Proteus
