143
Kaleido-X
User’s Manual
All silent / All silent
program 2
Select the level (in dB or dBFS for digital audio sources, in dB or dBu
for analog audio sources) below which an audio signal will be
considered silenced. An alarm is raised if all available channels are
below the threshold. The default value is –55
dBFS, on a range of -63
to 0.
Overload left/right Select the level (in dB or dBFS for digital audio sources, in dB or dBu
for analog audio sources) above which the audio signal will be
considered overloaded. The default value is –5
dBFS, on a range of -63
to 0.
Out of phase Select the sensitivity level below which the audio signal will be
considered out of phase. The sensitivity is a value between -1 and +1,
where -1 means completely out of phase and +1 means perfectly in
phase. The default value is 0.
Mono An audio source is considered to be mono if the left and right signals
are perfectly in phase (i.e. more likely to be the same). Select the
sensitivity level above which audio will be considered mono. The
sensitivity is a value between -1 and +1, where -1 means that
everything is considered to be mono, and +1 means that only
perfectly in phase audio will be considered mono. The default value is
1 (Perfectly in phase).
Metadata Calibration
DTVCC service
presence timeout
Set the delay (in seconds) after which a service presence timeout
alarm will be triggered. This calibration applies to the six standard
services. The default value is 30 seconds, on a range of 1 to 360.
DTVCC text
presence timeout
Set the delay (in seconds) after which a text presence timeout alarm
will be triggered. This calibration applies to the six standard services.
The default value is 30 seconds, on a range of 1 to 360.
Note: The video and metadata calibrations do not apply to the current
version of the KMV-3901/3911 multiviewer.
