350
Tally Interface Devices
Kahuna Production Switcher
4Touch the Protocols button on the screen to bring up the Engineering Config – Serial
Port Protocols menu.
5 In the list of RS-422 ports, select the one to which you connected the crossover cable.
6 Set the communications parameters for the selected port as follows, using the rotary
controls on the right of the GUI panel:
7 On the Kahuna switcher’s GUI panel, press the PERIPH button
The Peripherals menu appears.
8Touch the Tally Control button on the screen to bring up the Peripherals – Tally
Protocol menu.
9 Select the RS-422 port that is connected to the multiviewer, and set its serial protocol
options as follows:
To set up the multiviewer
1Open XEdit.
2 In the main window, click the System tab, and then click Description/Calibrations on
the second-level tab bar. The main pane displays the System hierarchical list, and the
Tools pane displays the equipment library when the root of the System list is selected.
3Drag the Kahuna production switcher device from the equipment library onto the root
of the System hierarchical list. Alternatively, right-click the list root, and then click Insert
Kahuna on the shortcut menu.
A window appears, prompting you for a device identifier.
Protocol Serial Tally
Baud Rate 115 200
Parity NONE
Data Bits 8
Stop bits 1
Port Type Master
Extension Enable On
Full Table Enable On
Notes
• Refer to the Kahuna User Instruction Manual for further details on setting up
the port protocols and tally protocol parameters (see
https://kahuna.snellgroup.com/kahunaclub/kahunacare/docu
ments.php
).
• Although it is possible to define “user configuration” source names on the
Kahuna switcher, these are not transmitted over the serial tally interface.
The switcher only transmits the “engineering configuration” source names.
