2. CNC Monitor Screen
2.7 Diagnosis
I - 171
Display item
Details
STS 5
This displays the control ou
tput signals to the NC.
Bit
Details
0 Current
detection
1 Speed
detection
2
3
4
5
6
In coil changeover
5L
7
8
1-amplifire 2-motor switching
9
2nd speed detection
A
B
C
D
E
In spindle holding force up
5H
F 2nd
in-position
STS 6
This displays the control ou
tput signals to the NC.
Bit
Details
0
1
2
3
4
5
6
6L
7
8
9
A
B
C
D
E
6H
F
195
197
