6. CNC Data Input/Output
6.4 Operation Windows
III - 37
6.4.7 Key Window
Key window is used to create a direcotry or output a file name.
2) Input value display area
4) Keyboard
1) Messag
3) Close button
[Key window display items]
No. Items Details
1 Message Displays a message.
In creating a directory, "Please input a directory name
。
" will be
displayed. In changing the name of an output file, "Please
input an output file name." will be displayed.
2 Input value display area Displays the input value.
Nothing is initially displayed in creating a directory. When
changing an output file name, the old file name is displayed.
An input value can be displayed within 28 characters.
3 Close button Pressing the button closes the window. Then the input value
will not be registered.
(Continued to the next page)
