2. CNC Monitor Screen
2.3(I) Tool Offset (L system)
(Refer to "2.3 (II). Tool Offset (M system)" for Machining center system)
I - 39
2.3(I) Tool Offset (L system)
The following menu will appear when the function key [TOOL PARAM] is pressed.
BACK NEXT
BACK NEXT
PARAM menu display(No.1 to 4)
TOOL menu display(No.1 to 4)
T-OFSET T-DATA NOSE-R LIFE MENU
Menu selection ke
y
Previous
p
a
g
e ke
y
Next page key
WORK PROCESS SETUP MENU
(Note)
WORK
OFFSET
PROCESS
PARAMETER
CONTROL
PARAMETER
AXIS
PARAMETER
(Note) "WORK OFFSET" is included in the TOOL menu.
CAUTION
If a tool offset amount is changed during automatic operation (including during single block stop),
the new offset is validated from the command of the next block or blocks onwards.
