Appendix 6. Operation Messages on Setting Display Unit
Appendix 6.2 Operator Messages
IV - 30
Appendix 6.2 Operator Messages
The following messages indicate the status of the setting and display functions‚ and are not operation errors.
They are mainly used to show that operation is normal‚ and serve as guides for the following operations.
There is no classification by numbers.
(1) Search and operation related
Message Message details
SEARCH EXECUTION
• Search is being executed normally.
SEARCH COMPLETE
• Search was completed normally.
(2) MDI/editing related
Message Message details
MDI NO SETTING
• Only display of MDI data (no execution)
MDI SETTING COMPLET
• The MDI data setting has been completed (execution is now
possible).
MDI ENTRY COMPLETE
• The MDI data was saved in the memory with the specified
program No.
MDI RUNNING
• The NC is operating with an MDI program‚ and the MDI data
cannot be corrected.
PUSH KEY
SEARCH/PROG
• Status in which no programs to be edited have been called on
the editing screen. To edit‚ press the SEARCH or PROGRAM
edit key.
EDITING
• The details of a program are being edited on the screen. Press
INPUT to write the data in the memory.
EDIT (REP.)
• The program can be edited on the screen in the replace mode.
EDIT (INS.)
• The program can be edited on the screen in the insert mode.
EDIT (CAN’T INSERT)
• The data can be inserted no more because of the shortage of
space area while editing the program on the screen with insert
mode. Cancel the insertion-impossible state by moving a cursor
and release some data area.
EDIT (CAN’T REPLACE)
• The data can be replaced no more since the cursor reached
the end of editing area while editing the program on the screen
with replace mode. Cancel the replace-impossible state by
cursor, DEL key, or C•B/CANCEL.
To Next Page
