6. CNC Data Input/Output
6.16 Various Status
III - 55
6.16.2 CNC Data
The following table shows the directories and files selected or displayed on the CNC data selection window.
Directory name Details File name in the
CNC
How the file is
recognized
when input into
CNC
INPUT OUT
PUT
Machining
programs
Machining programs ALL.PRG, .PRG
following 0
(Note 1) (Note 2)
Format in the
file
○ ○
Parameters Parameters ALL.PRM Format in the
file
○ ○
Tool offset Tool offset data TOOL.OFS Format in the
file
○ ○
Work offset Workpiece offset data WORK.OFS Format in the
file
○ ○
Common
variables
Common variables COMMON.VAR Format in the
file
○ ○
CNC Ladder USERPLC.LAD File name ○ ○
R resister data RREG.REG File name × ○
C resister data CREG.REG File name × ○
Operation history data TRACE.TRC File name × ○
T resister data TREG.REG File name × ○
CNC sampling data NCSAMP.CSV File name × ○
Maintenance
data
(Note 3)
SRAM data files SRAM.BIN File name × ○
Batch files related to
sampling (Note 4)
ALL.SMP File name ○ ○
Sampling setting file SAMPLING.PRM File name ○ ○
PLC data collection
setting file
PLCSAMP.CTF File extension ○ ○
PLC drawing setting
file
PLCSAMP.MMG File extension ○ ○
Cycle monitor
PLC data collection file PLCSAMPH.CSV File name × ○
(Note 1) If the base specifications parameter "#1166 fixpro" is set to "1", the fixed cycle programs will be the
target.
(Note 2) When CNC has more than one machining programs, "ALL. PRG" is shown at the top of the list.
(Note 3) The CNC ladder or register data file may not exist. In this case, the ladder with no step will be the
CNC ladder. When the data file of any register does not exist, the value of the register is set to "0"
(Note 4) Outputting "ALL.SMP" from CNC to a memory card outputs "SAMPLING.PRM", "PLCSAMP.CTF",
"PLCSAMP.MMG", and "PLCSAMPH.CSV" in batch. Inputting "ALL.SMP" from a memory card to
CNC inputs SAMPLING.PRM and PLCSAMP.CTF in batch. PLCSAMP.MMG and
PLCSAMPH.CSV will not be input but will be included in the SAMPLING.PRM.
(Note 5) "Can not write file" message will be displayed when attempting to enter a file that cannot be
entered.
(Note 6) When the "File name" is selected for "file identification method", not only the file names listed
above but also the names in "*(file name in CNC)*.(extension name)" format are selected. "*"
indicates any alphanumeric character.
