6. CNC Data Input/Output
6.16 Various Status
III - 56
[File names that are set as maintenance data file "USERPLC.LAD" in CNC]
USERPLC
.LAD
USERPLC
070408.LAD <- A part of the file name is contained.
_USERPLC
.LAD
BKUP_USERPLC
1.LAD
[File names that are not selected for the maintenance data file "USERPLC.LAD"]
USERPLC.LAD1
<- The file has different extension name.
Arbitrary file names and extensions of the files for machining programs, parameters, tool offset data and
common variables are recognized, because the file type is determined by the format in the files. The file
whose type is uncertain will be treated as machining program.
(Note 7) There is a relationship between a PLC collection setting file (PCSAMP.CFT) and a PLC drawing
setting file (PLCSAMP.MMG). Keep in mind the following two points when entering CNC data
- Enter both files with the combination when the sampling was executed and displayed.
- Enter a PLC collection setting file first, and then a PLC drawing setting file.
If not following these points, a sampled waveform may not be displayed. To display the sampled
waveform, move to the cycle monitor drawing setting screen and allocate a device.
