6. Operation Panel Switch Functions
6.15 Handle Interruption
II - 25
6.15.3 Interruption Effective Axis
(1) Automatic handle interruption is enabled only for axes to which manual handle axis selection has been
input.
(2) Automatic handle interruption is enabled for a maximum of three axes. (The number of axes is
restricted by the number of handles.)
6.15.4 Axis Movement Speed Resulting from Interruption
(1) The movement speed of the axis for which handle interruption is executed, may exceed the rapid
traverse feed rate during rapid traverse feed command (G00) processing in automatic start. To prevent
this, clamp the axis. (The movement speed equals Automatic-start movement speed + Speed resulting
from manual handle interruption.)
(2) The movement speed of the axis for which handle interruption is executed, may exceed the cutting
feed speed during cutting feed command (G01, G02, G03) processing in automatic start. To prevent
this, clamp the axis. (The movement speed equals Automatic start movement speed + Speed resulting
from manual handle interruption.)
(3) If, during automatic start, manual handle interruption is executed, in the same direction, for the axis
that is moving at an external decelerating speed, the axis movement speed may exceed the external
decelerating speed. To prevent this, clamp the axis. (The movement speed equals Automatic start
movement speed + Speed resulting from manual handle interruption.)
(4) If an attempt is made to execute interruption at a speed exceeding the clamp speed, the reading on the
handle scale does not match the distance of interruption.
(5) The handle scale factor depends on the selected input of the manual handle/step scale factor.
