6. CNC Data Input/Output
6.10 Deleting Files
III - 47
• Deleting all the machining programs in CNC
After selecting "CNC" at the step 4, follow the steps as shown below to delete.
.
5) Select "ALL.PRG" in the list.
ALL.PRG
1.PRG
2.PRG
3.PRG
"ALL.PRG" is highlighted. The file name area
shows "ALL.PRG".
ALL.PRG
1.PRG
2.PRG
3.PRG
6) Touch the Exec button.
The delete confirmation window appears.
7) Touch the OK button.
The message area shows "Deleting".
"Delete complete" is shown upon the
completion of delete.
(Note 1) When the data protection key 3, edit lock B and C are valid, the all deletion of machining programs
cannot be executed with ALL.PRG.
(Note 2) Cannot execute all files’ deletion on a memory card.
