III - 72
7. Data Backup and Restoration
7.2 PLC/CNC CPU Data Backup and Restoration
(5) Select the [Backup / Restoration] menu.
For GT15: [Debug & self check] - [Debug] - [Backup / Restoration]
For GT16: [Debug] - [Memory / Data control] - [Backup / Restoration function]
(6) When [Restoration function(Device->GOT)] is selected, backup files in the CF card are displayed in the
“Data list” screen. Select the files for the restoration.
(Note) Data name displayed in the "Date list" screen contains backup date and the number of backup.
Example: Backup data on 2009/04/05 is displayed as follow.
09040500 (1st backup)
09040501 (2nd backup)
Refer to "Backup Files Structure".
To Next Page
