Appendix 1. Registering and Editing Fixed Cycle Programs
Appendix 1.5 Standard Fixed Cycle Subprogram
IV - 12
G85 Boring 1 G86 Boring 2
O850 BORING-1 O860 BORING-2
G.1
IF[#30]GOTO1
Z#2G#6H#7
#2=##5#3003=#8OR1
G1Z#3
#3003=#8
Z-#3
G0Z-#2,I#23
N1M99
G.1
IF[#30]GOTO1
Z#2G#6H#7
#2=##5#3003=#8OR1
G1Z#3
G4P#4
M5
G0Z-#3-#2
#3003=#8
M3
N1M99
G87 Back boring G88 Boring 3
O870 BACK-BORING O880 BORING-3
G.1
IF[#30]GOTO1
Z#2G#6H#7
#2=##5#3003=#8OR1
G1Z#3
G4P#4
#3003=#8
M5
#3003=#8OR1
G0Z-#3-#2
#3003=#8
M3
N1M99
G89 Boring 4
O890 BORING-4
G.1
IF[#30]GOTO1
#3003=#8OR1
M19
X#12Y#13
#3003=#8
Z#2G#6H#7
#3003=#8OR1
G1X-#12Y-#13
#3003=#8
M3
#3003=#8OR1
Z#3
M19
G0X#12Y#13
Z-#2-#3
#3003=#8
X-#12Y-#13
M3
N1M99
G.1
IF[#30]GOTO1
Z#2G#6H#7
#2=##5#3003=#8OR1
G1Z#3
G4P#4
#3003=#8
Z-#3
G0Z-#2,I#23
N1M99
