IV - 117
Appendix 7. Explanation of Alarms
Appendix 7.8 Auxiliary Axis Operation Errors (M)
M00 Aux ax feedrate 0 0103 (Axis No. 1 to 4)
Details
The operation parameter's feedrate setting is zero.
The operation parameter feedrate setting is zero.
Or, the override is valid, and the override value is zero.
Remedy
- Set a value other than zero in the feedrate setting or override value.
M00 Aux ax sta No. illegal 0160 (Axis No. 1 to 4)
Details
A station No. exceeding the No. of indexed divisions was designated.
Remedy
- Correctly designate the station No.
M00 Aux ax R-pnt ret incomplete 0161 (Axis No. 1 to 4)
Details
Automatic/manual operation was started before reference position return was executed with
the incremental system.
Remedy
- Execute the reference position return.
M00 Aux abs position initializing 0162 (Axis No. 1 to 4)
Details
The start signal was input while initializing the absolute position reference point.
Remedy
- Complete the absolute position reference point initialization.
M00 Aux ax abs position error 0163 (Axis No. 1 to 4)
Details
The start signal was input during an absolute position alarm.
Remedy
- Initialize the absolute position reference point and then fix the absolute position
coordinates.
M00 Aux ax arbitrary positioning 0164 (Axis No. 1 to 4)
Details
The manual operation mode was started during the random positioning mode.
Remedy
- Turn the random positioning mode OFF before switching to the manual operation mode.
M00 Aux arbitrary coordinate index sta No. ilgl 0165 (Axis No. 1 to 4)
Details
The commanded station No. was higher than 20 or the number of indexing stations during
arbitrary coordinate indexing.
Remedy
- Check the commanded station No. and the parameter "#12801 station" setting.
- Designated station No.0 during arbitrary coordinate indexing.
