Appendix 7. Explanation of Alarms
Appendix 7.10 Multi CPU Errors (A)
A01 MULTI CPU ERROR 2124
Details
- A module is installed to the 65th or higher slot.
- A module is installed to the slot whose number is greater than the number of slots
specified in the base setting.
- A module is installed to the location corresponding to the I/O points of the 4,096 or greater.
- A module is installed to the slot whose assigned I/O range includes the limit of.
Remedy
- Remove the module installed to the 65th or later slot.
- Remove the module installed at the slot whose number is greater than the number of slots
specified in the base setting.
- Remove the module installed to the location of I/O points, 4,096 or greater.
- Replace the last module to a module which does not exceed the 4,096th point.
A01 MULTI CPU ERROR 2125
Details
- A module which the QCPU cannot recognize has been installed.
- There was no response form the intelligent function module/special function module.
Remedy
- Install a usable module.
- The intelligent function module is experiencing a hardware fault. Contact your local service
center.
A01 MULTI CPU ERROR 2140
Details
- Motion CPU (Q172LX, Q172EX (-S1, S2, S3) or Q173PX(-S1)) is mounted to the CPU slot
or slot No. 0 to 2.(QnUD(H)CPU does not lead this error.)
Remedy
- Remove the motion CPU that is mounted to the CPU slot or slot No. 0 to 2.
A01 MULTI CPU ERROR 2150
Details
- In a multiple CPU system, the control CPU of the intelligent function module incompatible
with the multiple CPU system is set to other than CPU No.1.
Remedy
- Change the intelligent function module for the one compatible with the multiple CPU
system (function version B).
- Change the setting of the control CPU of the intelligent function module incompatible with
the multiple CPU system to CPU No.1.
A01 MULTI CPU ERROR 2200
Details
- No parameter file is found all through the drives where the parameter should be validated.
Remedy
- Write the parameter file to PLC of the drive that validates the parameter.
A01 MULTI CPU ERROR 2210
Details
- The contents of the boot file are incorrect.
Remedy
- Check the boot setting.
