Appendix 8. User Parameters
【#8213(PR)】 Rotation axis type
Select the rotation type (short-cut enabled/disabled) or linear type (workpiece coordinate
linear type/all coordinate linear type).
This parameter is enabled only when "#1017 rot" is set to "1".
0: Disable short-cut
1: Enable short-cut
2: Workpiece coordinate linear type
(Note 1) When "2" is set, PLC axes will move as same as when "0" is set.
(Note2) The movement method varies as follows according to the rotary axis type you
designate.
<Workpiece coordinate value>
0,1 : Display range 0° to 359.999°
2 : Display range 0° to ±99999.999°
<Machine coordinate value/relative position>
0,1,2 : Display range 0° to 359.999°
<ABS command>
0 : The incremental amount from the end point to the current position is divided by
360, and the axis moves by the remainder amount according to the sign.
1 : Moves with a short-cut to the end point.
2 : In the same manner as the normal linear axis, moves according to the sign by the
amount obtained by subtracting the current position from the end point.
<INC command>
0,1,2 : Moves in the direction of the commanded sign by the commanded incremental
amount starting at the current position.
<Reference position return>
0,1,2 : The movement to the middle point follows the ABS command or the INC
command.
Returns with movement within 360 degrees from the middle point to reference
position.
【#8300】 P0 (for L system only)
Set the reference X-coordinates of the chuck and the tail stock barrier.
Set the center coordinate (radius value) of workpiece by the basic machine coordinate
system.
---Setting range---
-99999.999 to 99999.999 (mm)
【#8301】 P1 (for L system only)
Set the area of the chuck and tail stock barrier.
Set the coordinate from the center of workpiece (P0) for X-axis. (radius value)
Set the coordinate value by basic machine coordinate system for Z-axis.
---Setting range---
-99999.999 to 99999.999 (mm)
【#8302】 P2 (for L system only)
Set the area of the chuck and tail stock barrier.
Set the coordinate from the center of workpiece (P0) for X-axis. (radius value)
Set the coordinate value by basic machine coordinate system for Z-axis.
---Setting range---
-99999.999 to 99999.999 (mm)
