2. CNC Monitor Screen
2.2 Monitor
I - 29
Display item Explanation
[MACHINE]
X 12345.678
Y 0.000
Z-12345.678
A 0.000
B 359.999
C-12345.678
U 0.000
W 0.000
The coordinates of each axis in the basic machine coordinate
system, in which the zero point is determined depending on
the machine, are displayed.
[MODAL INFORM.]
G01..............G94
G67..............G50.1G43.1
G69: R=
The modal state of the current G command being executed is
displayed.
(Note) Fixed cycle operation:
When a fixed cycle command is executed, the G
command in the fixed cycle control subprogram does
not reflect the G modal of the calling source program.
G41: D =
G43: H =
H =
The tool radius compensation modal and offset number and
wear amount are displayed.
The tool length offset and offset number and wear amount are
displayed.
FA 1200.00
The modal value of the current program command F being
executed is displayed. (Unit: mm/min)
FM 0.00 The manual feed rate is displayed. (Unit: mm/min)
FS 0.0000 The manual feed rate is displayed. (Unit: mm/rev)
S1: 0
S2: 0
:
The modal value of the current program command S being
executed is displayed. (Up to two spindles)
T 12
The modal value of the current program command T being
executed is displayed.
M 0 77 88
A maximum of four modal values of the current program
command M being executed are displayed.
B 0
The second miscellaneous function modal value of the current
program command being executed is displayed.
G28 X0. Y0. Z0. ... The current program block being executed is displayed.
To Next Page
