5.2 FROM and TO Instructions
This section explains how to use FROM and TO instructions.
5.2.1 FROM instruction
FROM instruction reads data of the buffer memory in a special block.
1. Applicable devices
•For FX2N /FX2NC PLCs
•For FX
3U/FX3UC PLCs
2. Function and operation
1) 16-bit operation (FROM and FROMP)
Special function block (BFM)
→ PLC (word device)
"n" 16-bit data starting from buffer memory (BFM) No. m2 inside the special function block No. m1 are
transferred (read) to "n" devices starting from inside the PLC.
2) 32-bit operation (DFROM and DFROMP)
Special function block (BFM)
→ PLC (word device)
"n" 32-bit data starting from buffer memory (BFM) No. m2 inside the special function block No. m1 are
transferred (read) to "n" devices starting from [ +1, ] inside the PLC.
Operand
Type
Bit Devices Word Devices Others
System User Digit Specification System User Index Constant Pointer
X Y M T C S KnX KnY KnM KnS T C D V Z Modify K H P
m1
m2
n
Oper-
and
Type
Bit Devices Word Devices Others
System User Digit Specification System User
Special
Unit
Index
Con-
stant
Real
Number
Charac-
ter String
Pointer
XYMTCSD
.b KnX KnY KnM KnS T C D R
U\G
VZModifyKH E "
"P
m1
m2
n
D
D
D
Number of transfer points
n = 1 to 32767
FNC 78
FROM
m1 m2 nD
Unit No.
m1 = 0 to 7
Transfer source BFM #
(Special extension unit/block)
m2 = 0 to 32766
Transfer destination (PLC)
Command
D
D
FNC 78
DFROM
m1 m2 nD
Unit No.
m1 = 0 to 7
Transfer source BFM #
(Special extension unit/block)
m2 = 0 to 32765
Transfer destination (PLC)
Number of transfer points
n = 1 to 16383
Command
To Next Page
