1.3 Communication Type Applicability in PLC
1.3.1 For applicable versions
The communication types are applicable for the following versions.
: Applicable
—: Not applicable
*1. The table below shows PLC versions applicable to each inverter.
1. Version check
The D8001(decimal) special data register contains information for determining the PLC version.
PLC Applicability (applicable version) Remarks
FX
3UC Series
*1
F700, A700, E700, D700, V500, F500, A500, E500 and
S500 Series inverters can be connected.
FX
3U Series
*1
FX3G Series
*1
FX2NC Series
*1
A500, E500 and S500 Series inverters can be
connected.
FX
2N Series
*1
FX1NC Series — Inverter communication is not provided.
FX
1N Series — Inverter communication is not provided.
FX
1S Series — Inverter communication is not provided.
FX
0N Series — Inverter communication is not provided.
FX
0S Series — Inverter communication is not provided.
FX
0 Series — Inverter communication is not provided.
FX
2C Series — Inverter communication is not provided.
FX
2(FX) Series — Inverter communication is not provided.
FX
1 Series — Inverter communication is not provided.
PLC
FREQROL-
S500/E500/A500
FREQROL-F500/V500 FREQROL-F700/A700 FREQROL-D700/E700
FX
2N•FX2NC Ver.3.00 or later —
FX
3G Ver.1.10 or later
FX
3U Ver.2.20 or later Ver.2.32 or later
FX
3UC Ver.1.00 or later Ver.2.20 or later Ver.2.32 or later
D8001
PLC type and
version
2 4 2 5 1
Version information (Example: Ver. 2.51)
PLC type (Example: 24 = FX
2N
, FX
3U
, FX
2NC
or FX
3UC
Series)
