Mitsubishi FX2N-232-BD User Manual

B-10
FX Series PLC User's Manual - Data Communication Edition
N:N Network
2 Specifications
2.2 Link Specifications
2.2 Link Specifications
2.2.1 Link patterns and number of link points in each FX Series
The number of occupied link points varies depending on the number of slave stations used.
For example, when three slave stations are connected in "Pattern 1", M1000 to M1223 and D0 to D33 are
occupied, and unoccupied devices can be used as general devices for control.
(Link devices for unconnected slave stations can be used as general devices for control, but it is
recommended to leave them in the unoccupied status if slave stations may be added in the future.)
: Applicable
—: Not applicable
PLC Series Pattern 0 Pattern 1 Pattern 2
FX
3UC Series 
FX
3U Series 
FX
3G Series 
FX
2NC Series 
FX
2N Series 
FX
1NC Series 
FX
1N Series 
FX
1S Series  ——
FX
0N Series  ——
Station No.
Pattern 0 Pattern 1 Pattern 2
Bit
device (M)
Word
device (D)
Bit
device (M)
Word
device (D)
Bit
device (M)
Word
device (D)
0
4 in each
station
32 in each
station
4 in each
station
64 in each
station
8 in each
station
Master
station
Station
No. 0
— D 0 to D 3 M1000 to M1031 D 0 to D 3 M1000 to M1063 D 0 to D 7
Slave
stations
Station
No. 1
— D10 to D13 M1064 to M1095 D10 to D13 M1064 to M1127 D10 to D17
Station
No. 2
— D20 to D23 M1128 to M1159 D20 to D23 M1128 to M1191 D20 to D27
Station
No. 3
— D30 to D33 M1192 to M1223 D30 to D33 M1192 to M1255 D30 to D37
Station
No. 4
— D40 to D43 M1256 to M1287 D40 to D43 M1256 to M1319 D40 to D47
Station
No. 5
— D50 to D53 M1320 to M1351 D50 to D53 M1320 to M1383 D50 to D57
Station
No. 6
— D60 to D63 M1384 to M1415 D60 to D63 M1384 to M1447 D60 to D67
Station
No. 7
— D70 to D73 M1448 to M1479 D70 to D73 M1448 to M1511 D70 to D77
