FX Series PLC User's Manual - Data Communication Edition
Inverter Communication
9 Creating Programs (for FX3G, FX3U and FX3UC PLCs)
9.9 Second Parameter Specification Codes
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter Communication
F
Non-Protocol Communication (RS/RS2 Instruction)
G
Non-Protocol Communication (FX
2N
-232IF)
H
Programming Communication
I
Remote Maintenance
Apx.
Discontinued models
9.9.4 F500 Series
1. Second parameter specification codes for parameter numbers 902 to 905
9.9.5 V500 Series
1. Second parameter specification codes for parameter numbers 902 to 905
9.9.6 F700 Series
1. Second parameter specification codes for parameter numbers 125, 126, and C2 to C7
Parameter
No.
Name
Second parameter specification code
[(decimal) value to be specified in in IVRD/
IVWR instruction for parameter number]
Offset/Gain
(H00)
Analog
(H01)
Analog value of
terminal (H02)
902 Frequency setting voltage bias 902 1902 2902
903 Frequency setting voltage gain 903 1903 2903
904 Frequency setting current bias 904 1904 2904
905 Frequency setting current gain 905 1905 2905
Parameter
No.
Name
Second parameter specification code
[(decimal) value to be specified in in IVRD/
IVWR instruction for parameter number]
Offset/Gain
(H00)
Analog
(H01)
Analog value of
terminal (H02)
902 Speed setting No. 2 bias 902 1902 2902
903 Speed setting No. 2 gain 903 1903 2903
904 Torque command No. 3 bias 904 1904 2904
905 Torque command No. 3 gain 905 1905 2905
917 No.1 terminal bias (speed) 917 1917 2917
918 No.1 terminal gain (speed) 918 1918 2918
919 No.1 terminal bias (torque/magnetic flux) 919 1919 2919
920 No.1 terminal gain (torque/magnetic flux) 920 1920 2920
Parameter
No.
Name
Second parameter specification code
[(decimal) value to be specified in in
IVRD/IVWR instruction for parameter number]
C2 Terminal 2 frequency setting bias frequency 902
C3 Terminal 2 frequency setting bias 1902
125 Terminal 2 frequency setting gain frequency 903
C4 Terminal 2 frequency setting gain 1903
C5 Terminal 4 frequency setting bias frequency 904
C6 Terminal 4 frequency setting bias 1904
126 Terminal 4 frequency setting gain frequency 905
C7 Terminal 4 frequency setting gain 1905
S 2
S 2
S 2
