12.4.19 Operation mode display [D8389, D8419 and D8439]
These devices store the communication type being used.
1. Detailed contents
These devices store the code of the communication type currently being used in the communication port.
When communication port ch0 is used, D8389 stores the communication type.
When communication port ch1 is used, D8419 stores the communication type.
When communication port ch2 is used, D8439 stores the communication type.
The table below shows the contents of the communication type codes.
2. Cautions on use
These devices store "5" while RS2 instruction is being driven or when RS2 instruction is not changed over to
another mode.
Code Description
0 Programming communication
2 Protocol dedicated to computer link
3 N:N Network
4 RS instruction
5 RS2 instruction
6 Parallel link
7 Inverter instruction
8 Variable analog potentiometer expansion board is used.
