Mitsubishi FX2N-232-BD User Manual

D-17
FX Series PLC User's Manual - Data Communication Edition
Computer Link
3 System Configuration and Equipment Selection
3.2 Applicable FX PLC and Communication Equipment
A
Common Items
B
N:N Network
C
Parallel Link
D
Computer Link
E
Inverter Communication
F
Non-Protocol Communication (RS/RS2 Instruction)
G
Non-Protocol Communication (FX
2N
-232IF)
H
Programming Communication
I
Remote Maintenance
Apx.
Discontinued models
3.2 Applicable FX PLC and Communication Equipment
Select a (optional) communication equipment combination, and put a check mark in the "Check" column.
During selection, pay attention to the following:
- Computer link is not provided for the FX
0, FX0S, or FX1 Series.
3.2.1 For communication in accordance with RS-232C
FX Series Communication equipment (option)
Total extension
distance
Check
FX
0N
15 m
(49' 2")
FX
1S
15 m
(49' 2")
15 m
(49' 2")
FX
1N
15 m
(49' 2")
15 m
(49' 2")
FX
2N
15 m
(49' 2")
15 m
(49' 2")
FX 2NC -232ADP
(9-pin D-Sub, male)
FX 0N -232ADP
(25-pin D-Sub, female)
FX 1N -232-BD
(9-pin D-Sub, male)
FX 1N -CNV-BD
+
FX 2NC -232ADP
(9-pin D-Sub, male)
FX 0N -232ADP
(25-pin D-Sub, female)
FX 1N -CNV-BD
+
FX 1N -232-BD
(9-pin D-Sub, male)
FX 1N -CNV-BD
+
FX 2NC -232ADP
(9-pin D-Sub, male)
FX 0N -232ADP
(25-pin D-Sub, female)
FX 1N -CNV-BD
+
FX 2N -232-BD
(9-pin D-Sub, male)
+
FX 2NC -232ADP
(9-pin D-Sub, male)
FX 0N -232ADP
(25-pin D-Sub, female)
+
FX 2N -CNV-BD
FX 2N -CNV-BD
