E-22
FX Series PLC User's Manual - Data Communication Edition
Inverter Communication
4 Wiring
4.2 Selecting Cables and Connection Devices
4.2.4 E700 Series (FR-E7TR)
1. In the case of 1-to-1 connection
2. In the case of 1-to-N connection
When a distributor is not used
Terminal resistor
Twisted pair cable
FR-E7TR
FR-E7TRFR-E7TRFR-E7TR
When a distributor is not used
Terminal resistor
Twisted pair cable
Twisted pair cable Twisted pair cable
