Mitsubishi FX2N-232-BD User Manual

H-22
FX Series PLC User's Manual - Data Communication Edition
Programming Communication
3 Selecting Connection Cables
3.3 Combinations of Connection Cables
3.3 Combinations of Connection Cables
3.3.1 Handy programming panel
Programming tool
connector shape
Cable combination
PLC connector
shape
Cable
length
FX-10P(-E)
FX-20P(-E)
Standard built-in port
FX1N-422-BD
FX
2N-422-BD
FX
3G-422-BD
FX
3U-422-BD
1.5 m
(4' 11")
Standard built-in port
1.8 m
(5' 10")
Standard built-in port
1.5 m
(4' 11")
FX-10P-SET0(-E)
FX-20P-SET0(-E)
Standard built-in port
FX1N-422-BD
FX
2N-422-BD
FX
3G-422-BD
FX
3U-422-BD
1.5 m
(4' 11")
Standard built-in port
1.5 m
(4' 11")
P/I
8-pin MINI-DIN,
female
3
2
1
5
4
8
7
6
FX-20P-CAB0 [1.5 m (4' 11")]
... sold separately
RS-422
RS-422
8-pin MINI-DIN,
female
3
2
1
5
4
8
7
6
FX-20P-CAB [1.5 m (4' 11")]
... supplied with
FX-20P-CADP
[0.3 m (0' 11")] ...
sold separately
RS-422
RS-422
8-pin MINI-DIN,
female
3
2
1
5
4
8
7
6
FX-20P-CAB [1.5 m (4' 11")]
... supplied with
RS-422
RS-422
25-pin D-Sub,
female
13 1
25 14
P/I
8-pin MINI-DIN,
female
3
2
1
5
4
8
7
6
FX-20P-CAB0 [1.5 m (4' 11")]
... supplied with
RS-422
RS-422
8-pin MINI-DIN,
female
3
2
1
5
4
8
7
6
FX-20P-CAB [1.5 m (4' 11")]
... sold separately
RS-422
RS-422
25-pin D-Sub,
female
13 1
25 14
