Mitsubishi S12A2 - Stop Solenoid RUN off Type

8-8
Chapter 8 FUEL SYSTEM
Stop Solenoid - Remove and Inspect
3
10
11
1
5
2
6
4
7
8
9
Rotation
Looseness, bend
Stop solenoid RUN OFF type
Removing Sequence
1 Link
2 Bolt
3 Stop solenoid
4 Spring pin
5 Lever
6 Spring pin
7 Lever
8 Shaft
9 Snap ring
10 Ball bearing
11 Bracket
