12-5

Chapter 12 AIR START SYSTEM

1.3 Air Starter - Remove and Inspect

Air Starter - Remove and Inspect

Air starter motor starting spec

Removing Sequence

1 Clamp

2 Air motor (approx. 60 kg [132 lb])

3 Auto-muffler

4 Bracket

5 Bracket
