9-8
Chapter 9 LUBR
ICATION SYSTEM
1.4
Breather - Remove and Inspect
Breather - Remove and Inspect
1
5
1
1
3
2
2
4
4
55
3
3
1
2
3
3
1
4
5
5
2
Upward spec
Downward spec
Replace: Gasket
O-ring
Marine standard spec
MPTA spec
MPTK spec
Removing Sequence
1
Oil drain
p
ipe
2
Br
eather pipe
3
Stay
4
Rubber hose
5
Breather assembly
225
